TR - 825N Servo Mobile Tool Post Internal and External Wire Stripper（Outer Diameter of Wire: Within approximately 13mm）
TR - 825N Servo Mobile Tool Post Internal and External Wire Stripper（Outer Diameter of Wire: Within approximately 13mm）
TR - 825N Servo Mobile Tool Post Internal and External Wire Stripper（Outer Diameter of Wire: Within approximately 13mm）
TR - 825N Servo Mobile Tool Post Internal and External Wire Stripper（Outer Diameter of Wire: Within approximately 13mm）
TR - 825N Servo Mobile Tool Post Internal and External Wire Stripper（Outer Diameter of Wire: Within approximately 13mm）
TR - 825N Servo Mobile Tool Post Internal and External Wire Stripper（Outer Diameter of Wire: Within approximately 13mm）

TR - 825N Servo Mobile Tool Post Internal and External Wire Stripper（Outer Diameter of Wire: Within approximately 13mm）

Model
TR-825N

Item specifics

Power
AC220/110V/60HZ/50HZ
Name
wire cutting machine
Cutting length
0.1mm-99999.9mm
Scope of processing
Within approximately 13mm
Contact
CoCo +86 18666170785

Review

Description

TR - 825N Servo Mobile Tool Post Internal and External Wire Stripper
Power Supply: 220V 50 - 60Hz
Dimension and Weight: 660x600x1260mm, 120kg
Operation Interface: 7 - inch Touch Screen
Wire Cutting Length: 0.1 - 99999.9mm
Outer Skin Stripping Length: Front end 0 - 350mm; Rear end 0 - 150mm
Core Wire Stripping Length: 0 - 30mm
Wire Feeding Motor: Closed - loop/Servo
Conduit Control Method: Motor
Number of Motors: 9
Outer Diameter of Wire: Within approximately 13mm
Applicable Conduits: 8/10/12/14 (4 pieces)
Drive Method: 12 - wheel Drive Pulley for Wire Feeding
Production Capacity: Approximately 850 - 1000 pieces per hour (200mm - 1000mm)
